Xerox Phaser 6180MFP Service Manual

3-60 Phaser 6180MFP Multifunction Printer Service Manual
Error Messages and Codes
Insert Print Cartridge (Yellow/Cyan/Magenta/Black)
The printer does not detect the Print Cartridge. The following troubleshooting
procedure applies to these errors.
Applicable Chain Links
■ Chain Link 093-970: Insert Yellow Cartridge
■ Chain Link 093-971: Insert Magenta Cartridge
■ Chain Link 093-972: Insert Cyan Cartridge
■ Chain Link 093-973: Insert Black Cartridge
Initial Actions
■ Check the Print Cartridge life using CentreWare IS.
■ Cycle printer power.
■ If problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Print Cartridge Sensor, PL5.1.6
■ Print Cartridge (Y/M/C/K),
PL5.1.17-20
■ MCU Board, PL9.2.13
■ Toner Sensor Harness, PL10.1.7
■ “Developer” on page 10-38
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Check the Print Cartridge for correct
installation.
2.Is the Print Cartridge correctly
installed?
Go to step 3. Reseat the Print
Cartridge
(page 8-11)
2 Does the error still occur? Go to step 3. Complete.
3 1.Replace the Print Cartridge
(page 8-11).
2.Does the error still occur?
Go to step 4. Complete.

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
