Xerox Phaser 6180MFP Service Manual

3-138 Phaser 6180MFP Multifunction Printer Service Manual
Error Messages and Codes
Door A Open
The Front Cover is open. The following troubleshooting procedure applies to
this error.
Applicable Chain Link
■ Chain Link 077-300: Door A Open (IOT Front Cover Open)
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Front Cover, PL1.2.1
■ Interlock Harness, PL9.2.3
■ MCU Board, PL9.2.13
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Check the Front Cover for damages.
2.Are there any damages on the Front
Cover?
Replace the
Front Cover
(page 8-28).
Go to step 2.
2 Check the Interlock Switch for
operation.
1.Perform the Interlock Switch test
(page 4-44): Service Mode >
Printer Diag > Engine Diag >
Sensor Test > Interlock Switch.
2.Does the Switch operate properly?
Replace the
MCU Board
(page 8-88).
Go to step 3.
3 1.Replace the Interlock Switch
Harness (page 8-82).
2.Does the error still occur when the
printer is turned On?
Replace the
MCU Board
(page 8-88).
Complete.

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
