Phaser 6180MFP Multifunction Printer Service Manual 3-137
Error Messages and Codes
5 Does the error still occur when the
printer is turned On?
Go to step 6. Complete.
6 Check the Right Side Harness for
continuity.
1.Disconnect P/J25 from the MCU
Board.
2.Disconnect P/J251 from the Feed
Drive Assembly.
3.Check continuity between P/J25 <=>
P/J251.
Go to step 7. Replace the
Right Side
Harness.
7 Check the Drive Assembly signal.
1.Disconnect P/J25 from the MCU
Board.
2.Is there +24 V across ground <=>
J25-1/J25-2 pin on the MCU Board
when the Interlock Switch is
activated?
Replace the
Feed Drive
Assembly
(page 8-78).
Replace the
MCU Board
(page 8-88).
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
To Next Page
