Phaser 6180MFP Multifunction Printer Service Manual 3-203
Error Messages and Codes
Fax Communication Error
The Fax did not read the document in manual transmission. The following
troubleshooting procedure applies to this error.
Applicable Chain Link
■ Chain Link 033-763: Fax Communication Error (Manual Transmission
Read Manuscript Not Do)
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Scanner Controller Board, PL9.1.1
■ ADF Scanner Assembly, PL11.1.1
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Turn the printer power Off and back
On.
2.Does the error still occur when
faxing?
Go to step 2. Complete.
2 1.Replace the Scanner Controller
Board (page 8-99).
2.Does the error still occur when
faxing?
Replace the ADF
Scanner
Assembly
(page 8-103).
Complete.

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
