Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 2-73
Theory of Operation
Drive Assembly
The Drive Assembly transmits drive energy as shown in the following diagram.
Paper Handling
Process
s6180mfp-073
[Name of Moving Parts]
Drive Assembly
Tray 2 Motor
Tray 1 (MPT) Feed Solenoid
Tray 1 (MPT) Gear
[Tray 1 (MPT) Roller]
Tray 1 (MPT)
Turn Clutch Registration Clutch
[Turn Roller] [Rubber Registration Roller]
Rubber Registration Gear
Metal Registration Gear
[Metal Registration Roller]
Feeder
Feed Clutch
Oneway Nudger Clutch
[Feed Roller]
[Feed Roller]
Nudger Idler Gear
Nudger Roller Gear

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
