3-148 Phaser 6180MFP Multifunction Printer Service Manual
Error Messages and Codes
RAM Error
The printer controller has detected error. The following troubleshooting
procedure applies to this error.
Applicable Chain Link
■ Chain Link 116-315: RAM Error (ESS On Board RAM W/R Check Fail)
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Image Processor Board, PL9.1.20
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Check the Image Processor Board
for correct installation.
2.Is the Image Processor Board
correctly installed?
Go to step 2. Reseat the
Processor
Board
(page 8-90).
2 Does the error still occur when the
printer is turned On?
Replace the
Processor Board
(page 8-90).
Complete.
To Next Page
