Xerox Phaser 6180MFP - Repeating Defect Measurement

5-24 Phaser 6180MFP Multifunction Printer Service Manual
Print-Quality Troubleshooting
Repeating Defect Measurement
When horizontal lines and/or spot occur periodically, it is possibly caused by
the trouble of particular roller. Measure the trouble interval on the test print,
and check the relation to the Roller in the table. The interval does not
necessary match circumference of the Roller.
Horizontal Line and Spot Trouble Measurement
Roll
Roll
Diameter Interval Replacement
Part List
Number
Drum 24.0 mm
(.94 in.)
75.4 mm
(2.9 in.)
Print Cartridge (C/M/Y/K) PL5.1.17-20
BCR 9.0 mm
(.35 in.)
28.8 mm
(1.13 in.)
Print Cartridge (C/M/Y/K) PL5.1.17-20
BCR Cleaner Roll 8.0 mm
(.31 in.)
25.9 mm
(1.02 in.)
Print Cartridge (C/M/Y/K) PL5.1.17-20
Sleeve
(K)
16.0 mm
(.63 in.)
25.2 mm
(.99 in.)
Print Cartridge (K) PL5.1.17
Sleeve
(Y,M,C)
16.0 mm
(.63 in.)
22.3 mm
(.88 in.)
Print Cartridge (Y,M,C) PL5.1.18-20
1st BTR 12.0 mm
(.47 in.)
37.7 mm
(1.45 in.)
Transfer Unit PL4.1.1
ESA Roll 9.0 mm
(.35 in.)
28.3 mm
(1.11 in.)
Transfer Unit PL4.1.1
Drive Roll 18.1 mm
(.71 in.)
56.9 mm
(2.2 in.)
Transfer Unit PL4.1.1
Fuser Roll 26.32 mm
(1.01 in.)
82.7 mm
(1.3 in.)
Fuser PL6.1.10
Fuser Belt 30.0 mm
(1.2 in.)
94.2 mm
(3.7 in.)
Fuser PL6.1.10
Pinch Roll 6.0 mm
(.24 in.)
18.8 mm
(.74 in.)
Fuser PL6.1.10
Exit Roll 13.75 mm
(.54 in.)
43.2 mm
(1.7 in.)
Fuser PL6.1.10
Exit Pinch Roll 10.0 mm
(.4 in.)
31.4 mm
(1.24 in.)
Fuser PL6.1.10
