Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 3-153
Error Messages and Codes
Parallel Port Error
Parallel Port error has occurred. The following troubleshooting procedure
applies to this error.
Applicable Chain Link
■ Chain Link 116-367: Parallel Port Error (IEEE 1284 Data Error)
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Image Processor Board, PL9.1.20
■ Parallel Cable
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Check the Parallel cable connection.
2.Is the cable securely connected?
Go to step 2. Reconnect the
cable.
Go to step 2.
2 Does the error still occur? Replace the
Parallel Cable.
Go to step 3.
Complete.
3 Does the error still occur? Replace the
Processor Board
(page 8-90).
Complete.

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
