Error Messages and Codes
Network Error
Failure occurred on the Image Processor Board. The following
troubleshooting procedure applies to these errors.
Applicable Chain Link
■ Chain Link 116-350: Network Error (On Board Network Communication
Fail)
■ Chain Link 116-351: Network Error (On Board Network Ethernet BIST
Parity/RAM R/W Error)
■ Chain Link 116-352: Network Error (On Board Network Internal
Loopback Error)
■ Chain Link 116-355: Network Error (On Board Network Fatal Error)
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Image Processor Board, PL9.1.20
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Check the Image Processor Board
for correct installation.
2.Is the Image Processor Board
correctly installed?
Go to step 2. Reseat the
Processor
Board
(page 8-90).
Go to step 2.
2 Does the error still occur when the
printer is turned On?
Replace the
Processor Board
(page 8-90).
Complete.
