Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 3-113
Error Messages and Codes
Invalid Job
The controller has detetected incorrect data for the printing condition. The
following troubleshooting procedure applies to this error.
Applicable Chain Link
■ Chain Link 016-799: Invalid Job (Job Environment Violation)
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Image Processor Board, PL9.1.20
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Check the paper size.
2.Does the paper meet the
specifications?
Go to step 2. Replace the
paper.
2 1.Check the paper size setup on the
Control Panel: System > Tray
Settings > Tray 1/Tray 2 > Paper
Size.
2.Does the paper size in use match the
settings on the printer Control
Panel?
Complete. Go to step 3.
3 1.Set the paper size settings in the
Control Panel to match the paper in
the tray.
2.Does the error still occur when
printing?
Replace the
Processor Board
(page 8-90).
Complete.

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
