Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 4-105
General Troubleshooting
Abnormal Noise During Printing
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Retard Roll (Separator), PL2.1.7
■ Tray 2 Retard Roll, PL2.2.17
■ MPT Feed Roll, PL3.1.10
■ Metal Regi Roll, PL3.2.6
■ Rubber Regi Roll, PL3.2.7
■ Turn Roll, PL3.2.32
■ Tray 2 Feed Roll, PL3.2.53
■ Transfer Unit, PL4.1.1
■ Print Cartridge (C/M/Y/K),
PL5.1.17-20
■ Fuser, PL6.1.10
■ Main Drive, PL8.1.2
■ Drive Assembly, PL8.1.7
■ ADF Feed Roller & Pad, PL11.1.16
■ Duplex Unit, PL12.1.1
■ Optional 550-Sheet Feeder, PL13.1.1
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Check Tray 1 (MPT).
2.Does the noise come from Tray 1 when
paper is fed from Tray 1?
Go to step 2. Go to step 3.
2 1.Remove the paper from Tray 1.
2.Does the noise still occur?
Go to step 3. Go to step 4.
3 1.Check the paper condition.
2.Replace the paper.
3.Does the noise still occur?
Replace the
Tray 1 (MPT)
Retard Holder
Kit
(page 8-38).
Complete.
4 1.Check the Feeder for abnormal noise.
2.Does the noise come from the Feeder
while paper is feeding?
Go to step 5. Go to step 7.
5 1.Remove the paper from Tray 2.
2.Does the noise still come from the
printer?
Go to step 6. Complete.
6 1.Replace the paper.
2.Does the noise still come from the
printer?
Replace the
Tray 2 Retard
Roller
(page 8-15).
Complete.

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
