Xerox Phaser 6180MFP Service Manual

4-106 Phaser 6180MFP Multifunction Printer Service Manual
General Troubleshooting
7 1.Check the Duplex Unit for abnormal
noise.
2.Does the noise occur when feeding the
paper from the Duplex Unit?
Go to step 8. Go to step 10.
8 1.Check the Duplex Unit for correct
installation. Reseat the Duplex Unit
(page 8-115).
2.Does the noise still occur?
Replace the
Duplex Unit
(page 8-103).
Go to step 9.
9 1.Perform the Tray 2 Motor test
(page 4-56): Service Mode > Printer
Diag > Engine Diag > Motor Test >
Duplex Motor.
2.Does the noise still occur?
Replace the
Duplex Unit
(page 8-103).
Complete.
10 1. Check the ADF.
2.Does the noise occur when feeding the
paper from the ADF?
Go to step 11. Go to step 13.
11 1. Check the document.
2.Does the document meet the ADF
specifications?
Go to step 12. Change the
paper type.
12 1. Check the ADF Feed Roller and ADF
Separator Pad.
2.Are the parts damaged or are there any
contaminations on the parts?
Clean the
parts.
Replace the
ADF Feed
Roller
(page 8-110).
13 1. Check the Fuser for correct installation.
Reseat the Fuser (page 8-12).
2.Does the noise still occur?
Go to step 14. Complete.
14 1. Check the Transfer Unit for correct
installation. Reseat the Transfer Unit
(page 8-9).
2.Does the noise still occur?
Go to step 15. Complete.
15 1. Check the Print Cartridges for correct
installation. Reseat the Print Cartridges
(page 8-11).
2.Does the noise still occur?
Go to step 16. Complete.
16 1. Check the Main Drive Assembly for
correction installation. Reseat the Main
Drive Assembly (page 8-75).
2.Does the noise still occur?
Go to step 17. Complete.
17 1. Check the Feed Drive Assembly for
correct installation. Reseat the Feed Drive
Assembly (page 8-78).
2.Does the noise still occur?
Go to step 18. Complete.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
