Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 3-87
Error Messages and Codes
Multiple Feed
Multiple sheets of paper are fed concurrently. The following troubleshooting
procedure applies to this error.
Initial Actions
■ Inspect the tray to ensure that it is free of obstructions, is loaded with
supported paper, and the Guides are adjusted correctly.
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Retard Roll (Separator), PL2.2.7
■ MPT Feed Roll, PL3.1.10
■ Feeder Unit, PL3.2.1
■ Metal Regi Roll, PL3.2.6
■ Rubber Regi Roll, PL3.2.7
■ Turn Roll, PL3.2.32
■ Feed Roll, PL3.2.53
■ Retard Roll, PL13.2.10
■ Retard Roll (Nudger), PL13.4.10
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Check the paper feeding.
2.Does multiple feed occur?
Go to step 2. Go to step 3.
2 1.Check the paper. Replace the paper.
2.Does multiple feed still occur?
Replace the
following parts:
■ MPT Feed
Roller
(page 8-13)
■ Tray 2 Feed
Roller
(page 8-14)
■ Tray 3 Feed
Roller
(page 8-16)
■ Tray 2 Retard
Roller
(page 8-15)
■ Tray 3 Retard
Roller
(page 8-17)
Complete.

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
