Phaser 6180MFP Multifunction Printer Service Manual 3-91
Error Messages and Codes
Motor Error (Optional 550-Sheet Feeder)
The Optional 550-Sheet Feeder Motor has failed. The following
troubleshooting procedure applies to this error.
Applicable Chain Link
■ Chain Link 072-216: Option Feeder Motor Failure
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ MCU Board, PL9.2.13
■ Right Side Harness, PL10.1.12
■ 550-Sheet Feeder, PL13.1.1
■ Feed Roll, PL13.2.10
■ Optional Feeder Board, PL13.3.6
■ Optional Feeder Drive Assembly
PL13.3.10
■ Retard Roll, PL13.4.10
■ “Map 2 - Laser Unit and Feeder” on
page 10-11
■ “Map 4 - LVPS and MCU Board” on
page 10-13
■ “Map 6 - Optional 550-Sheet Feeder” on
page 10-15
■ “Optional 550-Sheet Feeder Wiring
Diagram” on page 10-45
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Check the paper tray for correct
installation.
2.Is the tray correctly installed?
Go to step 3. Reseat the
paper tray.
Go to step 2.
2 Does the error still occur when the
printer is turned On?
Go to step 3. Complete.
3 1.Check the Feed Rollers and Retard
Rollers for rotation.
2.Do the Rollers rotate smoothly?
Go to step 4. Replace the
defective
Roller(s).
4 1.Check the wiring harness
connectors P/J422, P/J4221, and P/
J4222 between the Tray 3 Feeder
Board and the Tray 3 Feeder Drive.
2.Are the connectors securely
connected?
Go to step 5. Reconnect the
connectors.
Go to step 5.
To Next Page
