Phaser 6180MFP Multifunction Printer Service Manual 3-205
Error Messages and Codes
Fax Codec Error
The Fax has failed. The following troubleshooting procedure applies to this
error.
Applicable Chain Link
■ Chain Link 033-773: Fax Codec Error (Undefined Marker Error)
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Scanner Controller Board, PL9.1.1
■ Fax Board, PL9.1.3
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Is the dial number correct? Go to step 2. Set the correct
dial number.
2 1.Check the Parameter setting:
Service Mode > Fax/Scanner Diag
Parameter.
2.Does Chain Link value 825-662
show on the Control Panel menu?
Go to step 3. Set the Chain
Link value to
825-662.
3 1.Check the country setting: System >
Admin Menu > Fax Settings >
Country.
2.Is the country setting correct?
Go to step 4. Set the country
setting to the
correct country.
4 1.Check the Fax Board for correct
installation. Reseat the Fax Board
(page 8-98).
2.Does the error still occur when
faxing?
Go to step 5. Complete.
5 1.Check the Scanner Controller Board
for correct installation. Reseat the
Scanner Controller Board
(page 8-99).
2.Does the error still occur when
faxing?
Replace the
Scanner
Controller Board
(page 8-99).
Complete.

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
