Xerox Phaser 6180MFP Service Manual

3-100 Phaser 6180MFP Multifunction Printer Service Manual
Error Messages and Codes
PDL Error
PDL Error has occurred. The following troubleshooting procedure applies to
this error.
Applicable Chain Link
■ Chain Link 016-720: PDL Error
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Image Processor Board, PL9.1.20
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the print job.
1.Print a small print job (example as a
Windows test print).
2.Does the error still occur?
Go to step 2. Complete.
2 1.Reseat the Image Processor Board
(page 8-90).
2.Does the error still occur?
Replace the
Processor Board
(page 8-90).
Complete.

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
