Xerox Phaser 6180MFP Service Manual

4-86 Phaser 6180MFP Multifunction Printer Service Manual
General Troubleshooting
+24 VDC Interlock Switch
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Interlock Harness, PL9.2.3
■ LVPS, PL9.2.4
■ LVPS Harness, PL10.1.3
■ “Map 4 - LVPS and MCU Board” on
page 10-13
■ “DC Power Supply” on page 10-24
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the Interlock Harness for continuity.
1.Disconnect P/J44.
2.Check continuity between P/J44-1 <=> P/
J44-3.
3.Is there voltage present when the
Interlock is activated?
Go to step 2. Replace the
Interlock
Switch
(page 8-82).
2 1.Disconnect the wiring harness
connectors P/J501 and P/J14.
2.Check continuity between P/J44-1 <=> P/
J44-3.
3.Is there +24 V present?
Go to “LVPS”
on page 4-84.
Replace the
LVPS
Harness.

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
