Phaser 6180MFP Multifunction Printer Service Manual 3-89
Error Messages and Codes
Options Errors
550 Feeder Error (Optional 550-Sheet Feeder)
The Optional 550-Sheet Feeder has failed. The following troubleshooting
procedure applies to this error.
Applicable Chain Link
■ Chain Link 072-215: 550 Feeder Error (IOT Option Feeder Failure)
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ MCU Board, PL9.2.13
■ Right Side Harness, PL10.1.12
■ Optional 550-Sheet Feeder, PL13.1.1
■ Feeder Unit Harness, PL13.3.3
■ Tray 3 Feeder Board, PL13.3.6
■ “Map 2 - Laser Unit and Feeder” on
page 10-11
■ “Map 4 - LVPS and MCU Board” on
page 10-13
■ “Map 6 - Optional 550-Sheet Feeder” on
page 10-15
■ “Optional 550-Sheet Feeder Wiring
Diagram” on page 10-45
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Check the Optional 550-Sheet
Feeder for correct installation.
2.Is the Optional 550-Sheet Feeder
correctly installed?
Go to step 3. Reseat the
Optional 550-
Sheet Feeder
(page 8-116).
Go to step 2.
2 Does the error still occur when the
printer is turned On?
Go to step 3. Complete.
3 1.Check the wiring harness
connectors P/J27, P/J273, and P/
J419 between the MCU Board and
the Tray 3 Feeder Board.
2.Are the connectors securely
connected?
Go to step 5. Reconnect the
connectors.
Go to step 4.
4 Does the error still occur when the
printer is turned On?
Go to step 5. Complete.
