Xerox Phaser 6180MFP Service Manual

3-186 Phaser 6180MFP Multifunction Printer Service Manual
Error Messages and Codes
Fax Codec Error
The Fax has failed. The following troubleshooting procedure applies to this
error.
Applicable Chain Link
■ Chain Link 033-510: Fax Codec Error
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Scanner Controller Board, PL9.1.1
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Turn the printer power Off and back
On.
2.Does the error still occur when
faxing after turning the printer back
On?
Go to step 2. Complete.
2 1.Check the Fax Parameter setting:
Service Mode > Fax/Scanner Diag
> Parameter.
2.Enter Chain Link 825-662.
3.Does the value [Hex] show number
2 (MMR)? (refer to “Chain Link for
Fax Parameter Setting” on page A-9
for detailed information)
Go to step 3. Change the
value ([Hex] to
2.
3 1.Check the Scanner Controller Board
for correct installation. Reseat the
Scanner Controller Board
(page 8-99).
2.Does the error still occur when
faxing?
Replace the
Scanner
Controller Board
(page 8-99).
Complete.

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
