3-6 Phaser 6180MFP Multifunction Printer Service Manual
Error Messages and Codes
Chain Link Definition
For Chain Link codes, Chain number (0 to 999) and Link number (0 to 999)
are assigned.
■Chain Number – Indicates target feature area. The Chain Number is
assigned based on Chain Number numbering guide.
â– Link Number - Assigned based on Link Number numbering guide. The
Fault type is defined by the Link Number.
The following table contains Chain Link definition for the Phaser 6180MFP.
Chain Link Definition for Printer
Chain Fail Group Link Definition
010 310~ Fuser
016 500~ Controller (ESS)
018 310~ Network Connect
024 310~, 910~ Controller (IOT)
041 310~ IOT
042 310~, 700~ IOT Fan Motor
061 310~ IOT (ROS)
071 100~ Tray 2
072 100~ Tray 3
075 100~ Tray 1 (MPT)
077 210~, 900~ Undefined Tray
092 600~ IOT (Sensor
093 310~, 910~ IOT (Developer, Print Cartridge,
CRUM)
094 310~, 910~ IOT (Transfer Unit)
116 310~, 910~ Controller (ESS)
117 310~ Controller (AIOC)
142 700~ IOT (Drive)
Chain Link for Scanner Controller
Chain Fail Group Link Definition
005 ADF 100~, 301~ ADF
016 500~ Controller (ESS)
017 Notice 910~ Controller (AIOC)
117 System Fail 310~ Controller (AIOC)
033 Job Fail 500~, 700~ Controller (Fax)
To Next Page
