Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 3-173
Error Messages and Codes
File Size Limit
File size error is over the maximum file size in file conversion. The following
troubleshooting procedure applies to this error.
Applicable Chain Link
■ Chain Link 016-986: File Size Limit (File Size Error)
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Scanner Controller Board, PL9.1.1
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Turn the printer power Off and back
On.
2.Does the error still occur?
Go to step 2. Complete.
2 1.Check the Country setting
information on the Control Panel:
System > Admin Menu > Fax
Settings > Country.
2.Is the Country setting correct?
Go to step 3. Change the
Country Setting
to the correct
country.
3 1.Check the Scanner Controller Board
for correct installation. Reseat the
Scanner Controller Board
(page 8-99).
2.Does the error still occur when the
printer is turned On?
Replace the
Scanner
Controller Board
(page 8-99).
Complete.

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
