Xerox Phaser 6180MFP Service Manual

1-2 Phaser 6180MFP Multifunction Printer Service Manual
General Information
Printer Introduction and Overview
The Xerox Phaser 6180MFP Multifunction Printer combines a color laser print
engine, a Scanner, Copier, and Fax. The Phaser 6180MFP has a single-pass
color laser-design architecture, which offers color and mono print speed at 20/
31-ppm, and resolutions up to 600 x 600 dots-per-inch (dpi). The printer
supports Adobe PostScript 3 and PCL6, USB 2.0, Parallel port, and 10/100
Base-TX Ethernet. The Scanner supports USB Scan to Desktop, Network
Scan to FTP, Network Scan to Server Message Block (SMB), and Network
Scan to E-Mail with resolution up to 600 dpi and interpolated up to 9600 dpi.
The Phaser 6180MFP provides a standard 150-Sheet Tray 1 (MPT) and a
standard 250-Sheet Tray 2. Tray 1 (MPT) supports specialty media, card
stock, and envelopes. The standard media input is 400 sheets and the
maximum input with an optional Tray 3 is 950 sheets. The Output Tray holds
300 sheets facedown.
The printer options add memory, media capacity, and functionality.
■ Memory upgrades are available to increase the standard RAM from 384
MB up to 1.4 GB maximum.
■ A 550-Sheet Feeder is available as an option.
■ Automatic 2-sided printing is available and no tools are required to install
the Duplex Unit.
■ The Multi-Protocol Network Card expands the supported network
protocols.
Technical Support Information
The Xerox Phaser 6180MFP Multifunction Printer Service Manual is the
primary document used for repairing, maintaining, and troubleshooting the
printer.
To ensure complete understanding of this product, participation in Xerox
Phaser 6180MFP Service Training is strongly recommended. To service this
product, Xerox certification for this product is required.
For updates to the Service Manual, Service Bulletins, knowledge base, etc.,
go to:
■ Xerox Global Service Net - https://www.xrxgsn.com/secure/main.pl
■ Service Partners: http://www.office.xerox.com/partners
For further technical support, contact your assigned Xerox Technical Support
for this product.

Xerox Phaser 6180MFP Specifications

General

Brand	Xerox
Model	Phaser 6180MFP
Category	All in One Printer
Language	English
