Xerox Phaser 6180MFP Service Manual

3-218 Phaser 6180MFP Multifunction Printer Service Manual
Error Messages and Codes
Fax Communication Error
The Fax has failed. The following troubleshooting procedure applies to these
errors.
Applicable Chain Link
■ Chain Link 035-702: Fax Communication Error (Receive DCN)
■ Chain Link 035-704: Fax Communication Error (Not Send Ability)
■ Chain Link 035-705: Fax Communication Error (DCS/NSS Resend Over)
■ Chain Link 035-708: Fax Communication Error (Post Message Resend
Over)
■ Chain Link 035-709: Fax Communication Error (G3 Send RTN/PIN
Receive)
■ Chain Link 035-710: Fax Communication Error (Receive PIN)
■ Chain Link 035-716: Fax Communication Error (T2 Time Out)
■ Chain Link 035-717: Fax Communication Error (G3 Receive RTN Send)
■ Chain Link 035-728: Fax Communication Error (G3 EOL Not Receive)
■ Chain Link 035-729: Fax Communication Error (Career Cut)
■ Chain Link 035-737: Fax Communication Error (CTC/EOR Resend Over)
■ Chain Link 035-739: Fax Communication Error (T5 Time Out)
■ Chain Link 035-740: Fax Communication Error (ECM Send EOR-Q
Send)
■ Chain Link 035-742: Fax Communication Error (ECM Receive EOR-Q
Receive)
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Scanner Controller Board, PL9.1.1

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
