Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 3-57
Error Messages and Codes
Print Cartridge CRUM Error (Yellow/Magenta/Cyan/Black)
The Print Cartridge CRUM communication is detected. The following
troubleshooting procedure applies to these errors.
Applicable Chain Link
■ Chain Link 093-925: Black CRUM Error
■ Chain Link 093-950: Yellow CRUM Error
■ Chain Link 093-951: Magenta CRUM Error
■ Chain Link 093-952: Cyan CRUM Error
Initial Actions
■ Check the Print Cartridge life using CentreWare IS.
■ Cycle printer power.
■ If problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Print Cartridge (Y/M/C/K),
PL5.1.17-20
■ CRUM Connector, PL5.2.1
■ MCU Board, PL9.2.13
■ CRUM Harness, PL10.1.9
■ “Map 2 - Laser Unit and Feeder” on
page 10-11
■ “Map 4 - LVPS and MCU Board” on
page 10-13
■ “Developer” on page 10-38
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Check the Print Cartridge(s) for
correct installation.
2.Is the Print Cartridge(s) correctly
installed?
Go to step 3. Reseat the Print
Cartridge(s)
(page 8-11).
Go to step 2.
2 Does the error still occur when the
printer is turned On?
Go to step 4. Complete.
3 Is the Print Cartridge a Xerox Print
Cartridge?
Go to step 5. Install a Xerox
Print Cartridge.
4 1.Check the CRUM Connector for
correct installation.
2.Is the connector securely
connected?
Go to step 5. Reseat the
CRUM
Connector
(page 8-56).
Go to step 5.

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
