Xerox Phaser 6180MFP Service Manual

3-102 Phaser 6180MFP Multifunction Printer Service Manual
Error Messages and Codes
MPC Error
MPC download has failed to start MPC download. The following
troubleshooting procedure applies to this error.
Applicable Chain Link
■ Chain Link 016-738: MPC Error (Download Initial Error)
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Image Processor Board, PL9.1.20
■ Multi-Protocol Network Card
(Option), PL9.1.23
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Check the Multi-Protocol Network
Card (MPC) for correct installation.
2.Is the MPC installed on the Image
Processor Board?
Go to step 2. Install the MPC
(page 8-95).
Go to step 2.
2 1.Check the firmware for the MPC.
2.Does the firmware have the correct
version?
Go to step 3. Update the
firmware
(“Firmware
Update” on
page A-3).
3 1.Check the MPC for correct
installation. Reseat the MPC
(page 8-95).
2.Does the error still occur after the
firmware has been updated?
Go to step 4. Complete.
4 1.Check the Image Processor Board
for correct installation. Reseat the
Image Processor Board
(page 8-90).
2.Does the error still occur after the
firmware has been updated?
Go to step 5. Complete.

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
