Xerox Phaser 6180MFP Service Manual

3-200 Phaser 6180MFP Multifunction Printer Service Manual
Error Messages and Codes
Fax Communication Error
The Fax job has failed. The following troubleshooting procedure applies to
these errors.
Applicable Chain Link
■ Chain Link 033-753: Fax Communication Error (CJ Not Detection)
■ Chain Link 033-754: Fax Communication Error (V8 Error)
■ Chain Link 033-755: Fax Communication Error (Phase2 Error)
■ Chain Link 033-756: Fax Communication Error (Phase3 Error)
■ Chain Link 033-757: Fax Communication Error (Primary Channel
Synchronization Error)
■ Chain Link 033-758: Fax Communication Error (Control Channel
Synchronization Error)
■ Chain Link 033-759: Fax Communication Error (Control Channel Retrain
Error)
■ Chain Link 033-760: Fax Communication Error (Control Channel Off
Time Out)
■ Chain Link 033-761: Fax Communication Error (Primary Channel Off
Time Out)
■ Chain Link 035-706: Fax Communication Error (Fall Back Error)
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Scanner Controller Board, PL9.1.1
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Is the dial number correct? Go to step 2. Set the correct
dial number.

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
