Xerox Phaser 6180MFP Service Manual

3-48 Phaser 6180MFP Multifunction Printer Service Manual
Error Messages and Codes
Fuser Error (IOT Fuser Life Over)
The Fuser has reached its end of life. The following troubleshooting procedure
applies to this error.
W
arn
i
ng
The Fuser may be hot. Turn the printer power Off and allow at least 5
minutes for the Fuser to cool before removing the Fuser.
Applicable Chain Link
■ Chain Link 010-351: Fuser Error (IOT Fuser Life Over)
Initial Action
■ Check the Fuser life using CentreWare IS.
■ Cycle printer power.
■ If problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Fuser, PL6.1.10
■ MCU Board, PL9.2.13
■ “Map 1 - Electrical and Drive” on
page 10-10
■ “Map 4 - LVPS and MCU Board” on
page 10-13
■ “Fuser” on page 10-40
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Check the Fuser life using CentreWare IS.
2.Does the Level show 0%?
Replace the
Fuser
(page 8-12).
Go to step 2.
2 Is the Fuser correctly installed? Go to step 3. Reseat the
Fuser
(page 8-12).
3 Does the error still occur when the power is
turned On?
Go to step 4. Complete.
4 1.Replace the Fuser (page 8-12).
2.Does the error still occur?
Replace the
MCU Board
(page 8-88).
Complete.

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
