Xerox Phaser 6180MFP Service Manual

3-126 Phaser 6180MFP Multifunction Printer Service Manual
Error Messages and Codes
Main Motor Error
The Main Motor has failed. The following troubleshooting procedure applies to
this error.
Applicable Chain Link
■ Chain Link 042-325: Main Motor Error (IOT Motor Failure)
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Transfer Unit, PL4.1.1
■ Print Cartridge (K), PL5.1.17
■ Fuser, PL6.1.10
■ Main Drive, PL8.1.2
■ MCU Board, PL9.2.13
■ Right Side Harness, PL10.1.12
■ “Map 1 - Electrical and Drive” on
page 10-10
■ “Map 4 - LVPS and MCU Board” on
page 10-13
■ “Main Drive” on page 10-28
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Check the Transfer Unit, Fuser, and
Black Print Cartridge for correct
installation.
2.Are the parts correctly installed?
Go to step 3. Reseat the
Transfer Unit
(page 8-9),
Fuser
(page 8-12),
and Black Print
Cartridge
(page 8-11).
2 Does the error still occur when the
printer is turned On?
Go to step 3. Complete.
3 1.Check the wiring harness
connectors P/J21 and P/J211
between the MCU Board and the
Main Drive.
2.Are the connectors securely
connected?
Go to step 5. Reconnect the
connectors.
Go to step 4.
4 Does the error still occur when the
printer is turned On?
Go to step 5. Complete.
