Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 3-127
Error Messages and Codes
5 1.Perform the Main Motor test
(page 4-54): Service Mode >
Printer Diag > Engine Diag > Motor
Test > Main Motor. During the test,
close the Front Cover.
2.Does the Motor operate properly?
Replace the
MCU Board
(page 8-88).
Go to step 6.
6 1.Check the Main Drive Assembly for
correct installation.
2.Is the Main Drive Assembly securely
installed?
Go to step 7. Reseat the Main
Drive Assembly
(page 8-75).
Go to step 7.
7 Does the error still occur when the
printer is turned On?
Go to step 8. Complete.
8 Check the Right Side Harness for
continuity.
1.Disconnect P/J21 from the MCU
Board.
2.Disconnect P/J211 from the Main
Drive Assembly.
3.Check continuity between P/J21 <=>
P/J211.
Go to step 9. Replace the
Right Side
Harness.
9 Check the Main Drive signal.
1.Disconnect P/J21 on the MCU
Board.
2.Is there +24 V across ground <=>
J21-2/J21-4 pin when the Interlock
Switch is activated?
Replace the
Main Drive
Assembly
(page 8-75).
Replace the
MCU Board
(page 8-88).
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
