Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 3-191
Error Messages and Codes
Task Error
The following troubleshooting procedure applies to these errors.
Applicable Chain Link
■ Chain Link 117-322: Error (SYSMGR Task Error)
■ Chain Link 117-328: Error (MSCAN Task Error)
■ Chain Link 117-335: Error (DFAX Task Error)
■ Chain Link 117-336: Error (PULL Task Error)
■ Chain Link 117-337: Error (IITTX Task Error)
■ Chain Link 117-340: Error (HOOK Task Error)
■ Chain Link 117-344: Error (FLASHFILE Task Error)
■ Chain Link 117-348: Error (IITRX Task Error)
■ Chain Link 117-349: Error (SCANMGR Task Error)
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Scanner Controller Board, PL9.1.1
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Turn the printer power Off and back
On.
2.Does the error still occur?
Go to step 2. Complete.
2 1.Check the Country setting
information on the Control Panel:
System > Admin Menu > Fax
Settings > Country.
2.Is the Country setting correct?
Go to step 3. Change the
Country Setting
to the correct
country.

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
