Xerox Phaser 6180MFP Service Manual

3-86 Phaser 6180MFP Multifunction Printer Service Manual
Error Messages and Codes
11 Check the Registration Sensor
Harness for continuity.
1.Disconnect P/J273 from the Feeder
Unit Harness.
2.Disconnect P/J27 from the MCU
Board.
3.Check continuity between P/J273
<=> P/J27.
Go to step 12. Replace the
Right Side
Harness.
12 Check the Optional Feeder Board
signal.
1.Disconnect P/J27 from the MCU
Board.
2.Is there +3.3 V across ground <=>
J27-B7 pin on the MCU Board?
Replace the
550-Sheet
Feeder
(page 8-116).
Replace the
MCU Board
(page 8-88).
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
