Xerox Phaser 6180MFP Service Manual

4-104 Phaser 6180MFP Multifunction Printer Service Manual
General Troubleshooting
17 1. Check the Feed Drive Assembly for
correct installation. Reseat the Feed Drive
Assembly (page 8-78).
2.Perform the Tray 2 Motor test
(page 4-56): Service Mode > Printer
Diag > Engine Diag > Motor Test > Tray
2 Motor.
3.Does the noise come from the printer?
Go to step 18. Complete.
If the
Optional 550-
Sheet Feeder
is installed,
go to step 18.
18 1. Perform the Option Feeder Motor test
(page 4-59): Service Mode > Printer
Diag > Engine Diag > Motor Test > Tray
3 Feed Motor.
2.Does the noise come from the printer?
Replace the
Optional 550-
Sheet Feeder
(page 8-116).
Complete.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
