Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 4-103
General Troubleshooting
11 1. Check the Print Cartridges for correct
installation. Reseat the Print Cartridges
(page 8-11).
2.Perform the Sub Motor test (page 4-55):
Service Mode > Printer Diag > Engine
Diag > Motor Test > Sub Motor.
3.Does the noise come from the printer?
Go to step 12. Complete.
12 1. Check the Main Drive Assembly for
correct installation. Reseat the Main
Drive Assembly (page 8-75).
2.Perform the Sub Motor test (page 4-55):
Service Mode > Printer Diag > Engine
Diag > Motor Test > Sub Motor.
3.Does the noise come from the printer?
Replace the
following
parts, one
after another.
■ Print
Cartridges (C/
M/Y/K)
(page 8-11)
■ Main Drive
Assembly
(page 8-75)
Complete.
13 1. Perform the Deve Motor test (page 4-57):
Service Mode > Printer Diag > Engine
Diag > Motor Test > Deve Motor.
2.Does the noise come from the printer?
Go to step 14. Go to step 17.
14 1. Remove the Print Cartridges (page 8-11).
2.Perform the Deve Motor test (page 4-57):
Service Mode > Printer Diag > Engine
Diag > Motor Test > Deve Motor.
3.Does the noise come from the printer?
Go to step 15. Complete.
15 1. Check the Print Cartridges for correct
installation. Reseat the Print Cartridges
(page 8-11).
2.Perform the Deve Motor test (page 4-57):
Service Mode > Printer Diag > Engine
Diag > Motor Test > Deve Motor.
3.Does the noise come from the printer?
Go to step 16. Complete.
16 1. Check the Main Drive Assembly for
correct installation. Reseat the Main
Drive Assembly (page 8-75).
2.Perform the Deve Motor test (page 4-57):
Service Mode > Printer Diag > Engine
Diag > Motor Test > Deve Motor.
3.Does the noise come from the printer?
Replace the
following
parts, one
after another.
■ Print
Cartridges (C/
M/Y/K)
(page 8-11)
■ Main Drive
Assembly
(page 8-75)
Complete.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
