Xerox Phaser 6180MFP Service Manual

3-54 Phaser 6180MFP Multifunction Printer Service Manual
Error Messages and Codes
4 Perform the Toner Motor test: Service
Mode > Engine Diag > Motor Test >
Toner Motor.
■ Yellow Toner Motor (page 4-61)
■ Magenta Toner Motor (page 4-62)
■ Cyan Toner Motor (page 4-63)
■ Black Toner Motor (page 4-64)
While testing the Toner Motor, close
the Interlock Harness.
Check the gear
of the Auger for
damage. If the
gear is
damaged,
replace the
Dispenser Motor
(page 8-59).
Go to step 5.
5 1.Check the Dispenser wiring harness
connectors.
■ Yellow: P/J18 and P/J181
■ Magenta: P/J18 and P/J182
■ Black: P/J18 and P/J183
■ Cyan: P/J18 and P/J184
2.Are the connectors securely
connected?
Go to step 6. Reconnect the
connectors.
Go to step 6.
6 Does the error still occur? Go to step 7. Complete.
7 Check the Top LV Harness for
continuity.
1.Disconnect P/J Harnesses.
■ Yellow: P/J18 and P/J181
■ Magenta: P/J18 and P/J182
■ Black: P/J18 and P/J183
■ Cyan: P/J18 and P/J184
2. Check continuity between P/J
connectors:
■ Yellow: P/J18 <=> P/J181
■ Magenta: P/J18 <=> P/J182
■ Black: P/J18 <=> P/J183
■ Cyan: P/J18 <=> P/J184
Go to step 8. Complete.
8 Check the Dispenser signal.
1.Disconnect P/J18 from the MCU
Board.
2.When the Interlock Switch is
activated, is there +24 V across:
■ Ground <=> P/J18-A1/P/J18-A2
pin (Yellow)
■ Ground <=> P/J18-A7/P/J18-A8
pin (Magenta)
■ Ground <=> P/J18-B1/P/J18-B2
pin (Black)
■ Ground <=> P/J18-B7/P/J18-B8
pin (Cyan)
Replace the
Dispenser
(page 8-59).
Replace the
MCU Board
(page 8-88).
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
