Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 3-51
Error Messages and Codes
4 Check the Fuser Harness for continuity.
1.Disconnect P/J17 from the MCU Board.
2.Disconnect P/J171 from the Fuser Unit.
3.Disconnect P/J47 from the LVPS.
4.Check continuity between P/J17 and P/
J47 <=> P/J171.
Go to step 5. Replace the
Fuser
Harness.
5 Check the LVPS Harness for continuity.
1.Disconnect P/J501 from the LVPS.
2.Disconnect P/J14 from the MCU Board.
3.Check continuity between P/J501 <=> P/
J14.
Go to step 6. Replace the
LVPS
Harness.
6 1.Replace the Fuser (page 8-12).
2.Does the error still occur?
Go to step 7. Complete.
7 1.Replace the LVPS (page 8-83).
2.Does the error still occur when the printer
is turned On?
Replace the
MCU Board
(page 8-88).
Complete.
Troubleshooting Procedure (continued)
Step Actions and Questions Yes No

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
