Phaser 6180MFP Multifunction Printer Service Manual 3-77
Error Messages and Codes
4 Check the Right Side Harness for
continuity.
1.Disconnect P/J23 from the MCU
Board.
2.Disconnect P/J231 from the Size
Switch Assembly.
3.Check continuity between P/J23 <=>
P/J231.
Go to step 5. Replace the
Right Side
Harness.
5 1.Replace the Tray 2 Size Switch
(page 8-74).
2.Does the error still occur when the
printer is turned On?
Replace the
MCU Board
(page 8-88).
Complete.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
To Next Page
