Phaser 6180MFP Multifunction Printer Service Manual 3-143
Error Messages and Codes
11 Check the Deve Motor for operation.
1.Perform the Deve Motor test
(page 4-72): Service Mode >
Printer Diag > Engine Diag > Motor
Test > Deve Motor. Close the Front
Cover while running the test.
2.Does the Deve Motor function
normally?
Go to step 13. Go to step 12.
12 1.Replace the Main Drive Assembly
(page 8-75).
2.Does the error still occur when the
printer is turned On?
Replace the
MCU Board
(page 8-88).
Complete.
13 1.Replace the corresponding Print
Cartridge (page 8-11).
2.Does the error still occur when the
printer is turned On?
Replace the
Laser Unit
(page 8-52).
Complete.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
