Xerox Phaser 6180MFP Service Manual

3-164 Phaser 6180MFP Multifunction Printer Service Manual
Error Messages and Codes
4 1.Check the Scanner Controller Board
for correct installation. Reseat the
Scanner Controller Board
(page 8-99).
2.Does the error still occur when
connecting to the server?
Replace the
Scanner
Controller Board
(page 8-99).
Complete.
5 1.Check the network connection.
Reseat the network connector.
2.Does the error still occur?
Go to step 6.
If an MPC Card
is not installed,
go to step 7.
Complete.
6 1.Check the MPC Card for correct
installation. Reseat the MPC Card
(page 8-95).
2.Does the error still occur when
connecting to the server?
Go to step 7. Complete.
7 1.Check the network setting: System >
Admin Menu > Network Settings.
2.Is the printer network setting
correct?
Go to step 8. Change the
Network Setting
information.
8 1.Check the Image Processor Board
for correct installation. Reseat the
Image Processor Board
(page 8-90).
2.Does the error still occur when
connecting to the server?
Replace the
Processor Board
(page 8-90).
Complete.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
