Xerox Phaser 6180MFP Service Manual

3-178 Phaser 6180MFP Multifunction Printer Service Manual
Error Messages and Codes
Scanner Error
The Scanner has failed. The following troubleshooting procedure applies to
these errors.
Applicable Chain Link
■ Chain Link 062-320: Scanner Error (Image Scanning Error)
■ Chain Link 062-321: Scanner Error (Scanner Malfunction)
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Scanner Controller Board, PL9.1.1
■ ADF Scanner Assembly, PL11.1.1
■ “Automatic Document Feeder Wiring
Diagram” on page 10-53
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Check the wiring harness
connectors P/J60, P/J62, P/J63, P/
J64, and P/J65 on the Scanner
Controller Board. Reseat the
connectors.
2.Does the error still occur when the
printer is turned On?
Go to step 2. Complete.
2 1.Replace the ADF Scanner Assembly
(page 8-103).
2.Does the error still occur when the
printer is turned On?
Replace the
Scanner
Controller Board
(page 8-99).
Complete.

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
