Xerox Phaser 6180MFP Service Manual

1-26 Phaser 6180MFP Multifunction Printer Service Manual
General Information
Scanning Scanner In operation (The Lamp is On.)
Control Panel Started condition
Scanner
Controller
Started condition
Printer Controller Started condition
Engine N/A
Engine Fan In operation
Faxing Scanner N/A
Control Panel N/A
Scanner
Controller
Started condition
Printer Controller N/A
Engine N/A
Engine Fan In operation
Ready Mode
Fixing The system keeps the standby temperature.
Exposure The system is at Stop status.
Recording The system is at Stop status.
Sleep Mode
Scanner Lamp On
Control Panel Back light Off.
LCD displays Ready.
Press any key to return to this state.
Scanner
Controller
Started condition
Printer Controller Started condition
Engine Ready (The Fuser is Off)
Engine Fan In operation
NOTE The Sleep mode is cancelled under the following conditions:
■ Any button on the Control Panel is pressed
■ A print job is started
■ A Fax job is started
Deep Sleep Mode (ENERGY STAR)
Scanner Lamp Off
Control Panel Back light off... LCD displays Ready.
Power Saver LED is On.
Press the Wake Up button to wake up the
printer.
Scanner
Controller
Wake Up key function is provided.
Operating Modes (continued)
Mode Sub System State

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
