5-58 Phaser 6180MFP Multifunction Printer Service Manual
Print-Quality Troubleshooting
5 1.Replace the ADF Scanner Assembly
(page 8-103).
2.Does the document feed correctly?
Complete. Go to step 6.
6 1.Check the paper condition.
2.Is the paper dry, recommended
type, and loaded in the correct
position?
Go to step 7. Replace the
paper.
7 1.Check the Front Cover Latch. Open
and close the Front Cover.
2.Does the error still occur?
Go to step 8. Complete.
8 1.Check the Transfer Unit for correct
installation. Reseat the Transfer Unit
(page 8-9).
2.Does the error still occur?
Go to step 9. Complete.
9 1.Check the Fuser for correct
installation. Reseat the Fuser
(page 8-12).
2.Does the error still occur?
Go to step 10. Complete.
10 1. Check the skewed tray.
2. Did the damaged paper feed from
Tray 1 (MPT)?
Go to step 11. Go to step 15.
11 1. Check the paper for correct
placement. Reseat the paper in Tray
1 (MPT).
2.Does the error still occur?
Go to step 12. Complete.
12 1. Check the Tray 1 (MPT) Side Guides.
Reseat the Side Guides.
2.Does the error still occur?
Go to step 13. Complete.
13 1.Check the paper path.
2.Are there any debris on the paper
path?
Remove the
debris.
Go to step 14.
14 1. Replace the Tray 1 (MPT) Feed
Roller (page 8-13).
2.Does the error still occur?
Replace the Tray
1 (MPT) Retard
Holder
(page 8-38).
Complete.
15 Did the damaged paper feed from the
Duplex Unit?
Go to step 16. Go to step 18.
16 1.Check the Duplex Unit for correct
installation. Reseat the Duplex Unit
(page 8-115).
2.Does the error still occur?
Go to step 17. Complete.
17 1.Check the paper path.
2.Are there any debris on the paper
path?
Remove the
debris.
Replace the
Duplex Unit
(page 8-103).
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
To Next Page
