Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 6-13
Adjustments and Calibrations
N
o
t
e
The default values are different in each printer.
Registration Values
Parameter Function Default
Adjustable
Range
Slow Scan K to P
(shifts 0.17 mm/1 count)
Black registration adjustment --- -128 to 127
Slow Scan 600 M, Y, C
(shifts 0.042 mm/1
count)
Color registration adjustment
(600 and 1200 dpi)
--- -60 to 60
Slow Scan 1200 M, Y, C
(shifts 0.021 mm/1
count)
Fast Scan Reg K to M, Y,
or C (shifts 0.042 mm/1
count)
Color registration adjustment
Calculation of adjustment is
shown below (exp. Yellow)
(Value of Fast Scan Reg K to Y +
Value of Fast Scan Reg2 K to Y)/4
--- -30 to 30
Fast Scan Reg2 K to M,
C, or Y
(shifts 0.01 mm/1 count)
--- -1 to 2
Fast Scan Reg Tray 1
(MPT), Tray 2, or Tray 3
(shifts 0.17 mm/1 count)
Black registration adjustment at
side 1 print
--- -30 to 30
Fast Scan Reg Duplex
(shifts 0.17 mm/1 count)
Black registration adjustment at
side 2 print
--- -30 to 30

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
