Phaser 6180MFP Multifunction Printer Service Manual 8-85
Service Parts Disassembly
19. Remove 1 screw (32 mm) securing the Duct Plate to the Fan.
20. Remove the Fan from the Duct Plate.
s6180mfp-314
Notch
Lug
Label
