DO NOT use the NVRAM ROM from the new I/P Board.
DO NOT apply pressure on the I/P Board when removing the NVRAM
ROM.
Make sure to move the NVRAM ROM from the old I/P Board to the
new I/P Board. Carefully check the correct orientation of the NVRAM
ROM when installing the NVRAM ROM.
Old Image Processor Board
New Image Processor Board
Notch
s6180mfp-319

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
