Xerox Phaser 6180MFP Service Manual

9-12 Phaser 6180MFP Multifunction Printer Service Manual
Parts List
Parts List 2.2 Tray 2 (2 of 2)
No. Name/Description Part Number
1. Cassette Assy Rear 250 (with 2-33)
2. Plate Assy BTM A4
3. Stopper PB
4. Gear BTM Lock Oneway
5. Shaft PB A4
6. Gear BTM DMP Oneway
7. Gear PB Left
8. Spring BTM Up 250 A4
9. Guide Assy Side Right 250 A4
10. Guide Assy Side Left 250 A4
11. Gear Pinion
12. Holder Assy Separator (with 13-18) 019K08510
13. Cover Retard CST (Tray Retard Cover)
14. Holder Separator
15. Shaft Separator
16. Clutch Friction Retard
17. Kit, Roll Assy Feed & Retard (Periodic Replacement Part - per 100K prints)
(consists of 3 pcs and tech sheet)
675K47671
18. Spring Separator
19. Switch Size Set
20. -----
21. Plate Gear Lock 250
22. Guide Assy Tray End 250
23. Actuator Size
24. Housing Base RE 250
25. Actuator Release PB
26. Spring Stopper Gear
27. Gear PB Right
28. Cover BTM Up 250
29. Rack BTM Lock 250
30. Spring BTM Lock
31. Gear BTM Lock Pinion
32. Gear Lever BTM Lock
33. Lever BTM Lock

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
