9-20 Phaser 6180MFP Multifunction Printer Service Manual
Parts List
Parts List 5.1 Xerographics (1 of 2)
ID No. Name/Description Part Number
1. Clamp RLMS-2V0
2. Frame Assy Earth
3. -----
4. Clamp RLWT-2V0
5. Clamp RLWC-3SV0
6. Clamp Saddle LES-1017
7. Foot
8. Clamp Saddle LES-1010
9. Clamp Saddle LED-0505
10. Bush STB-13
11. Spring ROS
12. ROS Assy GNB 604K42890
13. CORE (Ferrite Core)
14. Spacer Assy FFC
15. Film Assy Harness Guard
16. Clamp
17. Cartridge Assy (Print Cartridge) (K) (Periodic Replacement Part - per 8K prints) 113R00726
Cartridge Assy (Print Cartridge) (K) (Periodic Replacement Part - per 3K prints) 113R00722
Cartridge Assy (Print Cartridge) (K) (Periodic Replacement Part - Metered Print) 113R00734
18. Cartridge Assy (Print Cartridge) (C) (Periodic Replacement Part - per 6K prints) 113R00723
Cartridge Assy (Print Cartridge) (C) (Periodic Replacement Part - per 2K prints) 113R00719
Cartridge Assy (Print Cartridge) (C) (Periodic Replacement Part - Metered Print) 113R00731
19. Cartridge Assy (Print Cartridge) (M) (Periodic Replacement Part - per 6K prints) 113R00724
Cartridge Assy (Print Cartridge) (M) (Periodic Replacement Part - per 2K prints) 113R00720
Cartridge Assy (Print Cartridge) (M) (Periodic Replacement Part - Metered Print) 113R00732
20. Cartridge Assy (Print Cartridge) (Y) (Periodic Replacement Part - per 6K prints) 113R00725
Cartridge Assy (Print Cartridge) (Y) (Periodic Replacement Part - per 2K prints) 113R00721
Cartridge Assy (Print Cartridge) (Y) (Periodic Replacement Part - Metered Print) 113R00733
To Next Page
