9-24 Phaser 6180MFP Multifunction Printer Service Manual
Parts List
Parts List 6.1 Fuser & Exit
ID No. Name/Description Part Number
1. Chute Assy Exit Out (with 2-9, 16, 17) (attached on PL1.2.3) 054K30851
2. Spring Pinch Exit Out
3. Roll Pinch Exit
4. Spring CORR
5. Roll Corrugate
6. Holder CORR 2
7. Eliminator Exit 1
8. Spring Chute Out
9. Chute Exit Out 20
10. Fuser Assy KMY 115V (Periodic Replacement Part - per 100K prints) 675K47094
Fuser Assy KMY 230V (Periodic Replacement Part - per 100K prints) 675K47105
11. Harness Assy Fuser AIO 100V (P171-J17, J47) - (Harness Kit, Black & White) 604K44690
Harness Assy Fuser AIO 200V (P171-J17, J47) - (Harness Kit, Blue & Brown) 604K44690
12. Bracket Fuser
13. Chute Dup Gate 675K53460
14. Plate Latch FSR AD
15. Plate Latch FSR D
16. Tape Eliminator
17. Plate Earth Exit
To Next Page
