9-42 Phaser 6180MFP Multifunction Printer Service Manual
Parts List
Parts List 13.2 Optional 550-Sheet Feeder - Tray 3 (2 of 4)
ID No. Name/Description Part Number
1. Cover Front Left
2. Cover OPF Left
3. Cover CST 550
4. Clutch Assy Turn Opt
5. Clutch Assy Feed Opt
6. Cover OPF Right
7. Cover Front Right
8. Feeder Assy Opt Cabinet (with 1-7, PL13.3)
9. Feeder Assy Option 059K48273
10. Roll Assy Feed (Periodic Replacement Part - per 100K prints) 675K47670
To Next Page
