Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 9-49
Parts List
Harness Kits
Parts List
Reference Description
Part Number
99.99.96 Kit Harness Front Cover 604K44680
PL1.2.13 Harness Assy Front Cover (J272-P2720,
P2721, T4322-T43221)
962K39541
PL1.2.24 Harness Assy A-OP-OPP (J202-J5301) 962K45260
PL1.2.25 Harness Assy A-OP-ESS (J53-P5301) 962K45470
99.99.97 Kit Harness Feeder/Fuser/Interlock 604K44690
PL3.1.17 Harness Assy MPT NPP (J275-J2751) 962K41560
PL3.2.37 Harness Assy Regi Sensor
(J232-J2321, J2322)
962K38300
PL9.2.3 Harness Assy Interlock AIO 962K45360
PL10.1.3 Harness Assy LVPS AIO (J14-J141, J501) 962K45340
PL10.1.4 Harness Assy 24V AIO (J15-J502) 962K45330
PL10.1.5 Harness Assy Fuser AIO 100V
(P171-J17, J47)
962K45320
PL10.1.5 Harness Assy Fuser AIO 200V
(P171-J17, J47)
962K45270
PL10.1.16 Harness Assy Exit CLT (J276-J2761) 962K39600
99.99.98 Kit Harness Power Switch 604K44710
PL9.2.4 Power Switch 110K11570
PL9.2.16 Harness Assy Inlet AIO, 100 V (J48-J481) 962K45350
PL9.2.16 Harness Assy Inlet AIO, 220 V (J48-J481) 962K46460
PL10.1.6 Harness Toner Motor AIO
(J18-P181, P182, P183, P184)
962K45420
PL10.1.7 Harness Assy Toner Sensor AIO
(J19-J191, J192, J193, J194)
962K45410
PL10.1.9 Harness Assy CRU AIO
(J31-J311, J312, J313, J314)
962K45300
PL10.1.11 Harness Assy ESS Power AIO
(J40N-6N - J401-6N)
962K45381
PL10.1.13 Harness Assy IF AIO (J10, J40A, J504-
J101, J111, J401, J5041)
962K54503
PL10.1.14 Harness Assy AIO-ESS (J48-J480) 962K54503
PL10.1.15 Harness Assy HUM (J26-J261) 962K39480
PL10.1.17 Harness Assy Video AIO (J11-J111) 962K55422

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
