Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 10-35
Plug/Jack and Wiring Diagrams
Signal Line Name Description
CLOCK Controls signal of the EEPROM Belt.
DATA
ADC SOL ON (L) +24 VDC On/Off signal of the ADC Solenoid.
ADC SENSOR Detects toner patch density data measured by the ADC
Sensor (Analog value).
LED REM Provides remote signal of the LED of the ADC Sensor.
ADC V MONI Controls signal of the ADC Sensor.
DATA Controls signal of the EEPROM Board.
CLOCK
TEMP. Provides temperature data in the printer by the
Humidity/Temperature Sensor (Analog value).
HUMI. Provides Humidity/Temperature data in the printer by
the Humidity/Temperature Sensor (Analog value).
ERASE K ON (L) +3.3 VDC On/Off signal of the LED Assembly.
ERASE Y/M/C ON (L) +3.3
VDC

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
